Atlantic Typhoon Air Pumps TA1800-30LPM and TA3600-60LPM
- Maintain maximum O2 levels in summer, gas diffusion in winter
- Easy to clean air filter reduces particulates for motor longevity
- Most cost efficient way to keep an area free of ice in winter
- Aluminum housing radiates and reduces heat to extend diaphragm life
- Replaceable diaphragms for extended service life
- Includes ⅜" insert fitting for most vinyl air tubing or use stainless steel band clamp (not included) with ½" tubing over outlet
| Model | Item | Outlet | Volts | Watts | Max Pressure |
Max Depth |
Cord Length |
Dimensions | Warranty |
| TA1800 | 73941 | 3/8" insert, 1/2 slip | 115 | 25 | 3 psi | 7' | 6' | 6¾"L x 5"W x 5¼" H | 3 year Limited |
|---|---|---|---|---|---|---|---|---|---|
| TA3600 | 73942 | 3/8" insert, 5/8 slip | 115 | 35 | 5 psi | 11' | 6' | 7¼"L x 7"W x 6½" H | 3 year Limited |
| Model | Max | @1' | @2' | @3' | @4' | @5' | @6' | @8' | @10' | |
| TA1800 | LPM / CFM | 30 / 1.06 | 25 / 0.88 | 21 / 0.74 | 17 / 0.60 | 13 / 0.46 | 9 / 0.32 | 4 / 0.14 | -- | -- |
|---|---|---|---|---|---|---|---|---|---|---|
| TA3600 | LPM / CFM | 60 / 2.12 | 54 / 1.91 | 47 / 1.66 | 40 / 1.41 | 34 / 1.2 | 28 / 0.99 | 23 / 0.81 | 12 / 0.42 | 2 / 0.07 |
